EMINENCE USA DV-77 (8 ohm)

Was: $189.99
Now: $149.99
(0) Write a Review
SKU:
122711A-U
Weight:
0.00 LBS
Shipping:
Calculated at Checkout

Product Description

\n \nIntroducing the DV-77 Mick Thomson Signature Speaker. Designed by Mike Smith of OMEGA and Mick Thomson of Slipknot, this speaker represents the future of Mick's signature tone. Assembled in the USA by Eminence, the DV-77 leverages a new custom-designed basket, new voice coil design, new spider design, and a carefully chosen UK made Kurt Mueller cone to deliver exceptional tone and reliability. From the beginning, the focus of this speaker was balance, response, and a very musical tone. Delivering tight punchy lows, thick harmonically complex mid-range & detailed highs without excess fizz. Not a clone or a copy, this speaker was designed in the studio and proven on the stage. With over a year of real-world testing by Mick, the DV-77 Mick Thomson Signature Speaker is the perfect addition to your rig. \n \n  \n \n
\n
\n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n
SPECIFICATION
Nominal Basket Diameter12", 304 mm
Nominal Impedance*8 Ω
Power Rating*
Program PowerN/A
Watts70 W
Resonance70 Hz
Usable Frequency Range70 Hz - 5.3 kHz
Sensitivity*100.6 dB
Magnet Weight50 oz.
Gap Height0.313", 7.95 mm
Voice Coil Diameter1.75", 44 mm
THIELE & SMALL PARAMETERS
Resonant Frequency (fs)70 Hz
DC Resistance (Re)6.47 Ω
Coil Inductance (Le)0.49m H
Mechanical Q (Qms)11.46
Electromagnetic Q (Qes)0.45
Total Q (Qts)0.43
Compliance Equivalent Volume (Vas)71.19 liters / 2.51 cu.ft.
Peak Diaphragm Displacement Volume (Vd)41.04 cc
Mechanical Compliance of Suspension (Cms)0.19 mm/N
BL Product (BL)13.18 T-M
Diaphragm Mass Inc. Airload (MMs)27 grams
Efficiency Bandwidth Product (EBP)156
Maximum Linear Excursion (Xmax)0.79 mm
Surface Area of Cone (Sd)519.5 cm2
Maximum Mechanical Limit (Xlim)N/A
MOUNTING INFORMATION
Recommended Enclosure Volume
SealedAcceptable
VentedAcceptable
Driver Volume Displaced0.079 cu.ft. / 2.25 liters
Overall Diameter12.24", 310.9 mm
Baffle Hole Diameter11.09", 281.69 mm
Front Sealing GasketYes
Rear Sealing GasketYes
Mounting Holes Diameter0.25", 6.4mm
Mounting Holes B.C.D.11.69", 296.93mm
Depth5.19", 131.826 mm
Net Weight10.4 lbs, 4.72 kg
Shipping Weight12.1 lbs, 5.49 kgs
MATERIALS OF CONSTRUCTION
Coil ConstructionCopper voice coil
Coil FormerNomex former
Magnet CompositionFerrite magnet
Core DetailsNon-vented core
Basket MaterialsPressed steel basket
Cone CompositionPaper cone
Cone Edge CompositionPaper cone edge
Dust Cap CompositionZurette dust cap
